1 |
Working conditions |
-15℃∽40℃; RH＜80% |
|
2 |
Power supply |
AC 220V±10%; No limit on frequency |
|
3 |
AC high voltage output |
1000V∽2500V ±2%; Interval 200V; 50VA |
|
4 |
DC high voltage output |
500V ±2% |
|
5 |
Temperature control induction furnace |
Max power 500W |
|
6 |
Temperature control range |
<110℃ |
|
7 |
Temperature control error |
±0.5℃ |
|
8 |
Temperature test resolution |
0.1℃ |
|
9 |
Temperature control time |
Room temperature to 90℃ <20min |
|
10 |
Measuring range |
tgδC: xRx: |
No limit 15PF-300PF 10M-10T |
11 |
Resolution |
△ tgδ: △ Cx: △ Rx : |
0.001% 0.01pF 0.01 |
12 |
Accuracy |
△ tgδ: △ Cx: △ Rx: |
±(reading*0.5%+0.020%) ±(reading*0.5%+0.5PF) ±reading*10% |
13 |
Relative permittivity |
εr |
Automated calculated according to Cx, with the same accuracy as Cx |
14 |
Volume resistivity |
ρ |
Automatically calculated according to Rx, with the same accuracy as Rx |
15 |
Dimensions |
450（L）×310（W）×360（H）mm |
|
16 |
Weight |
18Kg |
|
