1. Power supply: AC(220±10%)V, 50 Hz
2. Heating power: Heater for distillation flask: 1300 W; Heater for receiver:350 W
3. Heating furnace of distillation flask: 0～1300 W, continuously adjustable
4. Temperature control point of air bath of receiver: Ambient to 100℃, continuously adjustable
5. Temperature sensor of air bath: Pt 100, RTD
6. Temperature control mode: Digital temperature controller
7. Temperature control precision: Set temp.±1℃
8. Capacity of buffer vessel: 1000 ml
9. Max. residual pressure: 2 mmHg
10. Digital pressure gauge:0~200 mmHg
11. Illumination light in the air bath: Energy saving lamp
12. Working condition: Ambient temp.15～35℃; RH< 85％
13. Dimension: 600mm×250mm×650mm
