1) 12 channels for time measurement (3-channel supports both the time contact and resistance contact time, 6-channel isolated contacts for cascaded unit measurement of pole)
   4 analog input channel. one for travel sensor and three for vibration sensors. All the three analog input channel can be used for other analog sensors also.
2) Time measurement
Range: 4000ms
Error :< 0.1ms
Resolution: 0.01ms
3) Travel measurement according to sensor:
Linear resistance sensor:
Measurement range: 0~250mm; resolution: 0.01mm; error: <0.5mm
Measurement range: 0~25mm; resolution: 0.01mm; error: <0.05mm
Angle resistance sensor:
Measurement range: 0~360°; resolution: 0.01°; error: <0.5°
4) Pre-insertion resistance measurement
Range: 50~5000ohm; error :<1%RDG+2D
5) Dynamic resistance measurement
Test current: 25~100A
Measurement error :< 1%RDG+2D
6) Contact resistance measurement
Range：0--10mohm
Error <0.5%RDG+0.05%FS
Range: 0-2mohm;
Error: <0.5%RDG+2D
7) Speed measurement
250mm linear resistance scale: 0~20m/s; error: <0.5%RDG+2D
25mm linear resistance scale: 0~20m/s; error: <0.5%RDG+2D
Angle sensor: 0~20m/s; error: <0.5%RDG+2D
Acceleration sensor: 0~20m/s; error: <5%RDG+2D
8) Coil current measurement
Range: 0~20A; resolution: 0.001A; error: <0.01A
9) Vibration measurement
Range: 0~5000G; error: <3%
10) Internal DC power source: voltage: 24~265V; current:0~20A
11) Built-in 8G storage memory and 2 USB interface for data export and external keyboard or mouse connection
12) Power supply: AC220V±10%; 50Hz±10%
13)Working environment: temperature: -10~50℃;  Humidity: <80%
14) Dimension and weight: dimension: 448×260×150mm; weight: 15kg
