Main Technical Data

Work Pressure: <10bar

Oil Viscosity: 0～350 cst

Flow Rate: 60～110ml/min

Power Supply: AC 180-250V, rechargeable lithium battery

Environment Temperature: -15℃～40℃

Oil Temperature: long time 0℃～55℃ (24Hour); short time <85℃ (10min)

Protection Level: IP67(case closed)

Dimension: 339mm × 295mm × 152mm (L × W × H)

Weight: About 4Kg

Specifications of Contamination

Particle Size Passage: 4µm(c), 6µm(c), 14µm(c), 21µm(c), 38µm(c), 70µm(c) and 5µm, 15µm, 25 µm, 50µm, 100µm

Test Standard: ISO 4406  0 ～24

          NAS 1638  00 ～12

          GJB 420B  00 ～12

Sensitivity: 1µm(ISO4402); 4µm(c) (ISO11171)

Repeatability Accuracy: ±0.5 ISO Level

Specifications of Oil Moisture

Measurement Range: relative humidity 0~100％RH, temperature -20~80℃

Resolution Ratio: relative humidity 0.1%RH, temperature 0.1℃

Measurement Accuracy: relative humidity≤ ±3%@ (0~80% RH) (0℃~60℃) % FS; temperature ±1℃FS
