SR-1 Online Oil Moisture Meter

Power Supply

AC 220V/50Hz (optional)

DC 9V～33V (standard configuration)

Signal Output

RS232 serial output

Two 4～20mA output，the maximum loop load 500Ω(optional)

(Dual channels can configure with output freely)

Two relay alarm output (optional)

(The alarm output type can be freely equipped. aw，t，ppm)

LCD Display

Switch water activity(aw),temperature(℃) and water content（ppm）at will.

Alarm Line Setting

The alarm value can be set by serial port setting software (aw,t,ppm)(optional)

Probe Type

Several types to choose as per user’s needs for the probe length.

Probe Cable Length

1m（Can be customized for other length）

Working Mode

Support on-line/off-line test

Required Test Temperature

Max Pressure

10 bar

Oil Temperature

-40℃～125℃

Water Activity Collection (aw)

Test Range

0～1 aw

Test Resolution

±0.0003 aw

Test Accuracy

±0.02 aw  @(0～0.8 aw)

Repeatability Error

±0.002 aw

Response Time with Stainless Steel Filter

10 min

Temperature Collection (T)

Test Range

-20℃ ～ 80℃

Test Resolution

0.015℃

Test Accuracy

±0.5℃ @(0～80℃)

Repeatability Error

≤ ±0.2℃

Response Time

30 s

Absolute Water (AH)

Test Range

0 ～ 1000 ppm

IP Grade

IP Grade of Probe

IP67

IP Grade of Shell

IP65
