Power Supply |
AC 220V/50Hz (optional) |
|
DC 9V～33V (standard configuration) |
||
Signal Output |
RS232 serial output |
|
Two 4～20mA output，the maximum loop load 500Ω(optional) (Dual channels can configure with output freely) |
||
Two relay alarm output (optional) (The alarm output type can be freely equipped. aw，t，ppm) |
||
LCD Display |
Switch water activity(aw),temperature(℃) and water content（ppm）at will. |
|
Alarm Line Setting |
The alarm value can be set by serial port setting software (aw,t,ppm)(optional) |
|
Probe Type |
Several types to choose as per user’s needs for the probe length. |
|
Probe Cable Length |
1m（Can be customized for other length） |
|
Working Mode |
Support on-line/off-line test |
|
Required Test Temperature |
Max Pressure |
10 bar |
Oil Temperature |
-40℃～125℃ |
|
Water Activity Collection (aw) |
Test Range |
0～1 aw |
Test Resolution |
±0.0003 aw |
|
Test Accuracy |
±0.02 aw @(0～0.8 aw) |
|
Repeatability Error |
±0.002 aw |
|
Response Time with Stainless Steel Filter |
10 min |
|
Temperature Collection (T) |
Test Range |
-20℃ ～ 80℃ |
Test Resolution |
0.015℃ |
|
Test Accuracy |
±0.5℃ @(0～80℃) |
|
Repeatability Error |
≤ ±0.2℃ |
|
Response Time |
30 s |
|
Absolute Water (AH) |
Test Range |
0 ～ 1000 ppm |
IP Grade |
IP Grade of Probe |
IP67 |
IP Grade of Shell |
IP65 |
|
