Item

Specifications

Spectral range

7800~350 cm-1

Resolution

better than 1.0 cm-1

Detector

High-sensitivity import detector

Beam splitter

KBr substrate plated with germanium,moisture-proof coating

Scan speed

Microcomputer control to select corresponding scanning speed, with continuously adjustable gears, and automatic spectrogram alignment.

Light source

Long-life and high-intensity air-cooled infrared light source (import)

Signal-to-noise ratio

better than 20000:1 P-P value

Linearity

<0.1%  (4400~500 cm-1, excluding water vapor and CO2）

Power supply

AC220V / 50Hz

Dimensions

355mm×265mm×160mm

Weight

9.6 kg

Data transmission interface

USB 2.0

Support system

Windows XP, Windows 7, Windows 10
