1. Power supply：AC（220±10%）V, 50Hz;
2. Heating power：≤2300W
3. Electric furnace heating power：1300W
4. Receiving cylinder：100 ml. Scale division 1 ml.
5. Distillation flask：125 ml, as per GB/T6536 and ASTM D86.
6. Thermometer：Total immersion. They are from ( -2 to 300 )℃ and from (-2 to 400) ℃. The scale divisions of them are 1 ℃.
7. Flask support board：Sic. Diameters of holes are φ32mm, 38mm, and 50mm.
8. Temperature controller of condensing tube：
(1) Range：0 ℃ to 60 ℃
(2) Display：LED
9.Temperature controller of receiving room：
(1) Range：0 ℃ to ambient
(2) Display：LED
10. Ambient temperature：15℃～28℃
  Relative humidity：≤85%
11. Dimension：540mm×435mm×515mm
12. Net weight：30kg.
