Technical Parameters
Standards |
GB265 ,GB1814,ASTM D445,IP71, etc. |
Capillary Viscometer |
SH/T0173-92 Technical Conditions of Glass Capillary Viscometer JJG155 Verification Regulation of Routine Capillary Viscometer |
Method of Display |
Precise digital temperature controller Highlighted digital stopwatch timer |
Temperature Control Range |
Arbitrary setting between room temperature~180℃(Refrigerator is required if need test temperature below room temp. Pls specially tell us if you need it) |
Testing Range |
Kinematic viscosity：0.5~!20000mm2/s Kinetic viscosity：0.3~40000mPa.s |
Temperature Control Accuracy |
±0.1℃ |
Timing Accuracy |
±0.1S |
Timing Range |
0.1S-999.9S |
Homoeothermic Bathtub |
250×250mm double layer |
Temperature Test Component |
Imported precision platinum electric resistance |
Stirring Speed |
1350 r/min |
Highest Power |
1200W |
Sample Quantity |
4 pieces |
Working Environment |
Ambient temperature: 15--35℃ Humidity: ＜85% |
Power Supply |
AC 220V±10%; 50Hz |
Dimension |
440*310*500（L*W*H） |
Weight |
Around 12Kg |
