Model |
SR-SGR-1L |
SR-SGR-2L |
SR-SGR-3L |
SR-SGR-5L |
Voltage/Frequency |
220V/50Hz |
|||
Motor Power (W) |
40 |
90 |
||
Heating Power (kW) |
1.5 |
2 |
||
Reaction Flask Volume (L) |
1 |
2 |
3 |
5 |
Glass Material |
GG-17 |
|||
Bottom Plate Main Support |
Stainless steel |
|||
Number of Bottle Openings on Lid |
5 |
|||
Reaction Temperature in Flask (°C) |
-80～250 |
|||
Vacuum Degree (MPa) |
0.098 |
|||
Stirring Speed (rpm) |
0～800 |
|||
Stirring Shaft Diameter (mm) |
8 |
|||
Speed Control Method |
Electronic stepless speed regulation |
|||
Condenser |
Vertical 40×400mm 24# standard port |
Vertical 60×450mm 24# standard port |
||
Drip Addition Device |
250ml constant pressure funnel 24# standard port |
500ml constant pressure funnel 29# standard port |
||
Pressure Reduction Device |
19# standard port pressure reducing valve |
24# standard port pressure reducing valve |
||
Temperature Measuring Tube |
19# standard port |
24# standard port |
||
Vacuum Display Method |
Vacuum gauge |
|||
Stirring Rod |
Anchor-type stainless steel bar, coated with PTFE |
|||
Stainless Steel Pot Dimensions (mm) |
245×140 |
265×160 |
280×170 |
|
